Mi-T-M CTM-3005-H6G0M Truck-Mount Pressure Washer – 3000 PSI, 5.0 GPM, Honda GX390
Mi-T-M CTM-3005-H6G0M: Truck-Mount Belt Drive Pressure Washer, 3000 PSI at 5.0 GPM
The Mi-T-M CTM-3005-H6G0M is a cold-water truck-mount belt-drive pressure washer producing 3000 PSI at 5.0 GPM through a Honda GX390 OHV engine and General pump with Mi-T-M Pressure Relief Start. Designed to bolt to a truck bed or trailer frame alongside a 200-gallon-plus water tank, it gives mobile cleaning contractors full self-sufficient operation on any site without requiring utility connections.
CTM-3005-H6G0M Mounting, Pump, and Drivetrain
- Powder-coated steel frame with 1¼-inch tube handles and rubber isolators — absorbs road vibration and provides secure bolt-down mounting points
- General pump with forged brass manifold and thermal relief valve — external bypass standard configuration protects pump on long transport between jobs
- 3/4-inch barb inlet — connects directly to trailer tank feed lines for consistent supply at 5.0 GPM flow rate
- Two-piece enclosed belt guard — protects belt alignment during rough-road trailer hauls
- Factory-optional CX-0127 electric start and CX-0128 battery tray — available for operators who require keystart convenience
Mobile Cleaning Operations Best Suited for the CTM-3005-H6G0M
Fleet washing companies that travel to customer sites use the CTM-3005-H6G0M mounted on a flatbed with a water tank, eliminating the need to find utility spigots. Construction equipment rental yards clean returned machines between customers using the 5.0 GPM flow rate to speed rinse cycles on dozers and excavators. Agricultural co-ops run the unit on a trailer for shared use across multiple farms, accessing any field with the Honda GX390's recoil start. The factory preset unloader reduces field adjustments, and the included 0°, 15°, 25°, and 40° nozzle set handles everything from concrete joints to vehicle panels in one stop.
Installation Requirements and Unit Specs
The CTM-3005-H6G0M requires mounting to a structure capable of supporting 210 lbs dynamic load. A minimum 200-gallon external water supply is recommended for sustained use. The 1.6-gallon onboard fuel tank suits shorter routes; factory optional fuel tank upgrades (CX-0129 10-gal, CX-0130 8-gal) extend range. The unit is not for sale in California.
| PSI | 3000 |
|---|---|
| GPM | 5.0 |
| Engine | 389cc Honda GX390 OHV |
| Pump | General |
| Unloader | Mi-T-M Factory Preset |
| Fuel Tank | 1.6 gallons |
| Net Weight | 210 lbs |
| Shipping Weight | 260 lbs |
| Dimensions (L×W×H) | 46 × 20.5 × 24 in. |
