Ebac RM4500 Whole House Ducted Dehumidifier – 150 PPD, 115V, DualCool, 10570RG-US
Ebac RM4500 10570RG-US Dehumidifier – 150 PPD, DualCool Technology
The Ebac RM4500 10570RG-US is a large-capacity restoration dehumidifier removing 150 pints per day using Ebac's DualCool HGR technology — a system that pre-cools and dehumidifies incoming air before the main refrigerant cycle, increasing extraction per watt. At 172 lbs and 1200W on a standard 115V circuit, it addresses large water damage events in commercial spaces that smaller 70-105 PPD units cannot clear efficiently. The high-capacity integral pump with purge handles drainage up to 10 feet of lift height.
Ebac RM4500 Extraction and Physical Specs
- Typical extraction: 150 PPD
- Voltage: 115V / 60Hz, 1-phase
- Power draw: 1200W / 12A
- Airflow: 700 m³/hr
- Noise level: 60 dBA
- Refrigerant: R407c
- Min operating temp: 37°F
- Max operating temp: 95°F
- Effective volume: 300 m³
- Weight: 172 lbs
- Dimensions: 43.8" H × 25.7" W × 24.8" D
- Pump lift: up to 10 ft (3m)
Where the RM4500 Is Deployed
Large commercial water damage events — flooded retail spaces, multi-room hotel suites, and office building water intrusions — where a single unit needs to match or exceed the combined output of two to three smaller units. The DualCool HGR system pre-treats incoming air, reducing the temperature and moisture load that reaches the main evaporator, resulting in sustained high extraction even as ambient humidity in the space drops during the drying process. The rotomolded polyethylene housing handles the demanding freight and handling conditions of active restoration fleet use.
Restoration Billing and Compliance
At 150 PPD the RM4500 falls above the 85 PPD threshold — bill as Xactimate WTRDHM>XL. ETL and CETL listed. The reverse-cycle defrost operates reliably at 37°F minimum. The 12A draw at 115V requires a 15- or 20-amp dedicated circuit; confirm circuit capacity before deployment in older buildings.
Specifications
| Part Number | 10570RG-US |
| Dimensions (H × W × D) | 43.8" × 25.7" × 24.8" |
| Weight | 172 lbs |
| Voltage | 115V / 60Hz, 1-phase |
| Power | 1200W / 12A |
| Airflow | 700 m³/hr |
| Typical Extraction | 150 PPD |
| Effective Volume | 300 m³ |
| Noise Level | 60 dBA |
| Refrigerant | R407c |
| Min Operating Temp | 37°F |
| Max Operating Temp | 95°F |
| Pump Lift Height | Up to 10 ft (3m) |
